Acid-Alkaline Resistant 316L Stainless Steel Bright Round Bar For Bearing
The stainless steel bars and rods are available in various sizes ranging from 3mm to 76.2mm,
we are also able to provide a cutting service to meet your individual requirements.
And we have a variety of materials for you to choose from,such as 201,304,316,316l, 904l,310s,309s,321,2205,2507 and more.
Material Specification include, but are not limited to, ASTM, AMS, ASME & QQ-A.
Products Description
| 1. Product: | Stainless steel round bar, stainless steel round rods, stainless steel shaft |
| 2. Diameter: | From Ø1/4'' to Ø16'' ( Diameter: 6mm~400mm ) |
| 3. Length: | 1~ 8meters |
| 4. Steel type: | 254SMO |
| 5. Standard: | ASTM 276, ASTM A564, ASTM A582, ASTM A484 |
| 6. Surface: | Bright, peeled, CNC machined, polished, or black etc, will be as per customers' request |
| 7. Diameter tolerance: | H9, H11, H13, K9, K11, K13 etc…as per clients' request etc |
| 8. Length tolerance: | 0/+50mm |
| 9. Finishing: | Solution treated |
| 12. Application: | Shipbuilding industry, marine shaft, propeller shaft, transmission shaft |
| bolt & nuts, machine-made industry, food industry, paper mill equipment. | |
| 13. Delivery time | Generally within 25 days, as per the q'ty. |
| 14. Certificate: | ISO, BV, TUV, SGS, mill test certificate |
| 15. Package: | Good quality & fumigated wooden box, can better protect the bars. ( See pictures below ) |
| 16. Experience:: | We have much experience in producing the stainless steel round bar, enjoy good reputations. |
Chemical Composition
| Chemical composition | |||||||
| Grade | C | Si | Mn | P | S | Ni | Cr |
| AISI 201 | <=0.15 | <=1.00 | 5.5-7.5 | <=0.060 | <=0.03 | <=3.50-5.50 | <=16.00-18.00 |
| AISI 202 | <=0.15 | <=1.00 | 7.5-10.0 | <=0.060 | <=0.03 | <=4.0-6.0 | <=17.00-19.00 |
| AISI 304 | <=0.07 | <=1.00 | <=2.00 | <=0.045 | <=0.03 | <=8.00-10.5 | <=18.00-20.00 |
| AISI 316L | <=0.03 | <=1.00 | <=2.00 | <=0.045 | <=0.03 | <=12.00-15.00 | <=16.00-18.00 |
| AISI 309S | <=0.08 | <=1.00 | <=2.0 | <=0.045 | <=0.03 | <=12.00-15.00 | <=22.00-24.00 |
| AISI 310S | <=0.08 | <=1.00 | <=2.00 | <=0.045 | <=0.03 | <=19.00-22.00 | <=24.00-26.00 |
| AISI 321 | <=0.08 | <=1.00 | <=2.00 | <=0.045 | <=0.03 | <=9.00-13.00 | <=17.00-19.00 |
| AISI 409L | <=0.08 | <=1.00 | <=1.00 | <=0.045 | <=0.03 | <=0.50 | <=10.50-17.50 |
| AISI 430 | <=0.12 | <=0.75 | <=1.00 | <=0.040 | <=0.03 | <=0.60 | <=16.00-18.00 |
| AISI 436L | <=0.025 | <=16.00-19.00 | |||||
| AISI 439 | <=0.03 | <=1.00 | <=1.00 | <=0.040 | <=0.03 | <=0.50 | <=17.00-19.00 |
| AISI 441 | <=0.015 | <=1.00 | <=1.00 | <=0.040 | <=0.03 | <=0.30 | <=17.50-19.00 |
| AISI 444 | <=0.025 | <=1.00 | <=1.00 | <=0.040 | <=0.03 | <=1.00 | <=17.50-19.50 |
Details Images
Packing & Delivery
20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
