TP 309S 904L 2205 2507 Inox Ss Pipe Aisi 347H 317L Stainless Steel Tube For Decorative
Mild Steel Pipe Hot Rolled is a tubular shaped pipe of hot rolled mild steel.
Hot rolled steel is formed through a metal rolling process where the steel is pressed at temperatures above the its recrystallization threshold.
|
Name
|
Stainless Welded Steel Pipe
|
|
|
|
Outer Diameter
|
10.3~610 mm
|
|
Wall Thickness
|
1.24~52.37 mm,Sizes can be customized
|
|
|
Length
|
Less Than 12 m
|
|
|
|
GB12771-91, ASTM A1053/A1053M-06, ASTM A268/A268M-05A, ASTM A269-07
|
|
|
ASTM A270-03A, ASTM A312/A312M-06, ASTM A358/A358M-05, ASTM A632-04
|
||
|
ASTM A789/A789M-05b, ASTM A790/A790M-05b, ASTM A872/A872M-07A, ASTM
|
||
|
A949/A949M-01(2005), ASTM A999/A999M-04A
|
||
|
|
Construction building material, curtain wall bracket, guardrail/handrailing material,
petroleum oil and gas transmission, coal, decoration, chemical engineering, food processing, agricultural use, indoor pipeline, water heater, boiler, bathtub etc. |
|
|
Ends Protector
|
Plastic pipe cap on both ends
|
|
|
Technique
|
Cold Rolled
|
|
|
Surface Finished
|
Polishing grit400/grti600/grti800 ect
|
|
|
Section Shape
|
Round, Bevled
|
|
|
|
Inner Packing:Caps at both ends, steel strong trips on every bundle,
Outer Packing:PE Wrapping outside, Export Standard Packing Method(Bundle with steel strip, steel pallet), shipped with 20' or 40' container or in bulk carrier. As Customers' Request. |
|
|
Port
|
Xingang Port,Tianjin, China
|
|
|
Date of Delivery
|
According To The Quantity And Specification Of Each Order
|
|
|
Payment
|
T/T, Western Union, Alibaba Trade Assurance
|
|
| C | Mn | P | S | Si | Cr | Ni | Mo | |
| TP304 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 18.00-20.00 | 8.00-11.00 | |
| TP304L | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 18.00-20.00 | 8.00-11.00 | |
| TP316 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| TP316L | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 16.00-18.00 | 10.00-15.00 | 2.00-3.00 |
| TP321 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 17.00-19.00 | 9.00-12.00 | |
| TP347H | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 17.00-19.00 | 9.00-12.00 |
| Standard | Materail | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | Hardness(HRB) |
|
ASTM |
201 | ≥515 | ≥260 | ≥40 | ≤95 |
| 304 | ≥515 | ≥260 | ≥40 | ≤95 | |
| 316L | ≥485 | ≥170 | ≥30 | - | |
| 430 | ≥450 | ≥205 | ≥22 | ≤89 |
