Precision Stainless Steel Pipes Cold Rolled Steel 201 304 316 Stainless Steel Tube For Tableware
What is cold rolled stainless steel?
Cold rolling technology refers to a process whereby steel or stainless steel metals are rolled at room temperature rather than being heated to 1100 degrees Celsius. Rolling steel at room temperature by passing it through rollers enables shaping.
|
Name
|
Stainless Welded Steel Pipe
|
|
|
|
Outer Diameter
|
10.3~610 mm
|
|
Wall Thickness
|
1.24~52.37 mm,Sizes can be customized
|
|
|
Length
|
Less Than 12 m
|
|
|
|
GB12771-91, ASTM A1053/A1053M-06, ASTM A268/A268M-05A, ASTM A269-07
|
|
|
ASTM A270-03A, ASTM A312/A312M-06, ASTM A358/A358M-05, ASTM A632-04
|
||
|
ASTM A789/A789M-05b, ASTM A790/A790M-05b, ASTM A872/A872M-07A, ASTM
|
||
|
A949/A949M-01(2005), ASTM A999/A999M-04A
|
||
|
|
Construction building material, curtain wall bracket, guardrail/handrailing material,
petroleum oil and gas transmission, coal, decoration, chemical engineering, food processing, agricultural use, indoor pipeline, water heater, boiler, bathtub etc. |
|
|
Ends Protector
|
Plastic pipe cap on both ends
|
|
|
Technique
|
Cold Rolled
|
|
|
Surface Finished
|
Polishing grit400/grti600/grti800 ect
|
|
|
Section Shape
|
Round, Bevled
|
|
|
|
Inner Packing:Caps at both ends, steel strong trips on every bundle,
Outer Packing:PE Wrapping outside, Export Standard Packing Method(Bundle with steel strip, steel pallet), shipped with 20' or 40' container or in bulk carrier. As Customers' Request. |
|
|
Port
|
Xingang Port,Tianjin, China
|
|
|
Date of Delivery
|
According To The Quantity And Specification Of Each Order
|
|
|
Payment
|
T/T, Western Union, Alibaba Trade Assurance
|
|
| C | Mn | P | S | Si | Cr | Ni | Mo | |
| TP304 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 18.00-20.00 | 8.00-11.00 | |
| TP304L | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 18.00-20.00 | 8.00-11.00 | |
| TP316 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| TP316L | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 16.00-18.00 | 10.00-15.00 | 2.00-3.00 |
| TP321 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 17.00-19.00 | 9.00-12.00 | |
| TP347H | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 17.00-19.00 | 9.00-12.00 |
| Standard | Materail | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | Hardness(HRB) |
|
ASTM |
201 | ≥515 | ≥260 | ≥40 | ≤95 |
| 304 | ≥515 | ≥260 | ≥40 | ≤95 | |
| 316L | ≥485 | ≥170 | ≥30 | - | |
| 430 | ≥450 | ≥205 | ≥22 | ≤89 |
