904L Stainless Steel Pipe N08904 Corrosion Resistant Ss Seamless Pipe For Kitchen
904L stainless steel pipe (00Cr20Ni25Mo4.5Cu) is austenitic stainless steel with better corrosion resistance. Because of the addition of 1.5% copper, it also has excellent corrosion resistance to reducing acids such as sulfuric acid and phosphoric acid. In addition, It has low carbon properties for welding purposes.
|
Name
|
Stainless Welded Steel Pipe
|
|
|
|
Outer Diameter
|
10.3~610 mm
|
|
Wall Thickness
|
1.24~52.37 mm,Sizes can be customized
|
|
|
Length
|
Less Than 12 m
|
|
|
|
GB12771-91, ASTM A1053/A1053M-06, ASTM A268/A268M-05A, ASTM A269-07
|
|
|
ASTM A270-03A, ASTM A312/A312M-06, ASTM A358/A358M-05, ASTM A632-04
|
||
|
ASTM A789/A789M-05b, ASTM A790/A790M-05b, ASTM A872/A872M-07A, ASTM
|
||
|
A949/A949M-01(2005), ASTM A999/A999M-04A
|
||
|
|
Construction building material, curtain wall bracket, guardrail/handrailing material,
petroleum oil and gas transmission, coal, decoration, chemical engineering, food processing, agricultural use, indoor pipeline, water heater, boiler, bathtub etc. |
|
|
Ends Protector
|
Plastic pipe cap on both ends
|
|
|
Technique
|
Cold Rolled
|
|
|
Surface Finished
|
Polishing grit400/grti600/grti800 ect
|
|
|
Section Shape
|
Round, Bevled
|
|
|
|
Inner Packing:Caps at both ends, steel strong trips on every bundle,
Outer Packing:PE Wrapping outside, Export Standard Packing Method(Bundle with steel strip, steel pallet), shipped with 20' or 40' container or in bulk carrier. As Customers' Request. |
|
|
Port
|
Xingang Port,Tianjin, China
|
|
|
Date of Delivery
|
According To The Quantity And Specification Of Each Order
|
|
|
Payment
|
T/T, Western Union, Alibaba Trade Assurance
|
|
| C | Mn | P | S | Si | Cr | Ni | Mo | |
| TP304 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 18.00-20.00 | 8.00-11.00 | |
| TP304L | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 18.00-20.00 | 8.00-11.00 | |
| TP316 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| TP316L | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 16.00-18.00 | 10.00-15.00 | 2.00-3.00 |
| TP321 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 17.00-19.00 | 9.00-12.00 | |
| TP347H | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 17.00-19.00 | 9.00-12.00 |
| Standard | Materail | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | Hardness(HRB) |
|
ASTM |
201 | ≥515 | ≥260 | ≥40 | ≤95 |
| 304 | ≥515 | ≥260 | ≥40 | ≤95 | |
| 316L | ≥485 | ≥170 | ≥30 | - | |
| 430 | ≥450 | ≥205 | ≥22 | ≤89 |
