TP201 202 304 316l 321 Stainless Steel Tube Hollow Stainless Steel Small Round Tube For Building
Stainless steel pipe is a kind of hollow long round steel, which is mainly used in industrial transportation pipelines and mechanical structural components such as petroleum, chemical industry, medical treatment, food, light industry, mechanical instrument and so on. In addition, when the bending and torsional strength are the same, the weight is lighter, so it is also widely used in the manufacture of mechanical parts and engineering structures. It is also commonly used as furniture and kitchenware.
|
Name
|
Stainless Welded Steel Pipe
|
|
|
|
Outer Diameter
|
10.3~610 mm
|
|
Wall Thickness
|
1.24~52.37 mm,Sizes can be customized
|
|
|
Length
|
Less Than 12 m
|
|
|
|
GB12771-91, ASTM A1053/A1053M-06, ASTM A268/A268M-05A, ASTM A269-07
|
|
|
ASTM A270-03A, ASTM A312/A312M-06, ASTM A358/A358M-05, ASTM A632-04
|
||
|
ASTM A789/A789M-05b, ASTM A790/A790M-05b, ASTM A872/A872M-07A, ASTM
|
||
|
A949/A949M-01(2005), ASTM A999/A999M-04A
|
||
|
|
Construction building material, curtain wall bracket, guardrail/handrailing material,
petroleum oil and gas transmission, coal, decoration, chemical engineering, food processing, agricultural use, indoor pipeline, water heater, boiler, bathtub etc. |
|
|
Ends Protector
|
Plastic pipe cap on both ends
|
|
|
Technique
|
Cold Rolled
|
|
|
Surface Finished
|
Polishing grit400/grti600/grti800 ect
|
|
|
Section Shape
|
Round, Bevled
|
|
|
|
Inner Packing:Caps at both ends, steel strong trips on every bundle,
Outer Packing:PE Wrapping outside, Export Standard Packing Method(Bundle with steel strip, steel pallet), shipped with 20' or 40' container or in bulk carrier. As Customers' Request. |
|
|
Port
|
Xingang Port,Tianjin, China
|
|
|
Date of Delivery
|
According To The Quantity And Specification Of Each Order
|
|
|
Payment
|
T/T, Western Union, Alibaba Trade Assurance
|
|
| C | Mn | P | S | Si | Cr | Ni | Mo | |
| TP304 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 18.00-20.00 | 8.00-11.00 | |
| TP304L | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 18.00-20.00 | 8.00-11.00 | |
| TP316 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 |
| TP316L | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 16.00-18.00 | 10.00-15.00 | 2.00-3.00 |
| TP321 | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 17.00-19.00 | 9.00-12.00 | |
| TP347H | 0.08 | 2.00 | 0.045 | 0.03 | 1.00 | 17.00-19.00 | 9.00-12.00 |
| Standard | Materail | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | Hardness(HRB) |
|
ASTM |
201 | ≥515 | ≥260 | ≥40 | ≤95 |
| 304 | ≥515 | ≥260 | ≥40 | ≤95 | |
| 316L | ≥485 | ≥170 | ≥30 | - | |
| 430 | ≥450 | ≥205 | ≥22 | ≤89 |
